Only 5RU high and 6 inches deep, the Videohub 72 is designed to accept a mix of SDI interface, crosspoint, and power supply cards, as your application sees fit. When you're ready to upgrade, all SDI interface cards, crosspoint and power supply cards can be installed into the larger Universal Videohub 288 chassis.įor more information on this or any other Blackmagic Design product, visit . The Blackmagic Design Universal Videohub 72 Rack Frame is a customizable rack frame that lets you build your own 72 x 72 SDI router. Router connections preserved and restored instantly at power on independently of host computer. Redundant power supply options are available, as well as a GPI alarm for connecting external alarms.
VIDEOHUB 72 MAC OS
Router control software included free for Windows and Mac OS X.įirmware upgrade provided via included firmware updater application. With no electronic components on the router motherboard, every single part can be replaced simply by hot-plugging cards.Ĭross-points are monitored constantly, and instantly change when a fault is detected!
VIDEOHUB 72 FULL
Other features include a removable fan tray, full auto standard detection, re-clocking, 3Gb/s SDI support, 72 x 72 deck control, and ethernet/serial control. Add up to 18 BNC SDI or optical fiber SDI interfaces along with a single 72 x 72 crosspoint and power card. Only 5RU high and 6" deep, the Videohub 72 is designed to accept a mix of SDI interface, crosspoint, and power supply cards, as your application sees fit. The Blackmagic Design Universal Videohub 72 is a customizable rack frame that lets you build your own 72 x 72 SDI size router. For maximum flexibility, interface cards are all the same size and fit both Universal Videohub 72 and Universal Videohub 288, which is great if you need to use an alternative frame size in the future.Blackmagic Design Universal Videohub 72 Rack Frame SDI and optical fiber interface cards also support 16 channels of embedded SDI audio, so all the audio channels in your signal are routed together with the video. The Universal Videohub Deck Control Cable breaks out to 4 separate RS-422 connections.
VIDEOHUB 72 PLUS
Simultaneously route copper SDI and optical fiber SDI signals in the same router.Įach SDI and optical fiber SDI interface card features 4 inputs and 4 outputs, plus a breakout cable port for deck control. The design also integrates crosspoint and power redundancy and when you need to expand you can use the same interface cards in a larger frame.ģ Gb/s SDI connections automatically switch between SD, HD, 4:4:4 and 2K video formats, so you can move the highest quality video between all your editing systems, decks, monitors and more. Universal Videohub models feature a frame-based design with the freedom to build a router to suit your needs. You can hot swap interface cards while working live without the need to power down the router. Universal Videohub 72 lets you add up to 18 interface cards, and Universal Videohub 288 up to 72 cards, which is great for broadcast and post facilities with lots of equipment. Only Universal Videohub lets you upgrade to a larger rack frame and protect your investment in interface cards and power supplies!
Route directly from one SDI or optical fiber device to another, from SDI to optical fiber or vice versa. That’s great for use in larger facilities and for large scale events.
Get incredible 3 Gb/s SDI routing, plus the ability to send and receive video signals over long distances using optical fiber. Universal Videohub is perfect for when you need to route SDI and optical fiber connections. Mix and match interfaces and build a router with all SDI, all-optical fiber SDI or a combination of both. Every interface module in the router is card based, with each card featuring 4 inputs and 4 outputs. Universal Videohub frames come in a choice of two sizes that let you expand your router up to either a 72 x 72 or 288 x 288 crosspoint size. The Blackmagic Universal Videohub 72 Full Router lets you build your own broadcast quality 3 Gb/s SDI and optical fiber SDI router for SD, HD, 4:4:4 and 2K video formats.
